Every sound board we carry, side by side. Compare the specs, get the app, and look up the button and gesture controls for your saber.
Schematic 01Compare the boards
Board readout
| RGB S16, RGB | S-RGB, RGB | SN Pixel V4.0, Neopixel | Proffie V2.2, Neopixel | |
|---|---|---|---|---|
| Blade colors | 12 colors | 12 colors | 12 preset colors | 25 preset colors |
| Sound fonts | 16 sets | 27 sets (preset) | 27 sets (preset) | 25 (preset) |
| Ignition effects | No | No | 11 effects | 25 effects, changed with sound fonts |
| Blade | 32/36″ RGB blade | 32/36″ RGB blade | 32/36″ pixel blade, built-in double-sided LED strip | 32/36″ pixel blade, built-in double-sided LED strip |
| Speaker | 4Ω 3W | 4Ω 3W | 4Ω 3W | 4Ω 2W |
| Battery | 2000mAh 18650 | 2000mAh 18650 | 3200mAh 18650 | 3200mAh 18650 |
| SD card | No | 32GB | 32GB | 32GB |
| Bluetooth app | No | Yes, iOS & Android | Yes, iOS & Android | No |
| Combat effects | Blaster, Lock-up, Flash on Clash (FOC) | Blaster, Lock-up, FOC | Blaster, Lock-up, FOC, Melt, Force, Drag | Blaster, Lock-up, FOC, Melt, Force, Drag |
| Customization | None | SD card customize function | SD card customize function | SD card customize function (32GB) |
| Seller suggestion |
|
|
|
|
| Controls | Controls coming soon | Controls for the S-RGB | Controls for the SN Pixel V4.0 | Controls for the Proffie V2.2 |
All boards
- Blade effects
- Gesture control
- LED light
- Swing on / smooth swing
- Volume adjustment
- Removable battery
- Removable electronic kit
- Background music
- Charging reminder
Uplink · ForcePark V2Bluetooth pairing
Pair your saber
Works with the S-RGB and SN Pixel V4.0 over Bluetooth, with a 32GB SD card.
- Convenient
- Efficient
- Intelligent
On an iPhone, search “ForcePark V2” in the App Store.
App functions
- Sensitivity adjustment
- Blade DIY
- Sound fonts DIY
- Infinite color changing
- Ignition on/off
- More functions to explore
Archive 03Button codes
Control codes
Pick your board and how many buttons your hilt has.
Board
Buttons
SN Pixel V4.0 · 1 button
Standby · button
- Switch pixel number
- Tap the button 3 times when power is off.
- Enter standby mode
- Hold the button until the button light is on.
- Enter boot status
- Tap the button after entering standby mode.
- Volume adjust
- Hold until the breath light flashes once, then release.
- Switch boot effect
- Hold until it flashes twice, then release.
- Switch blade effect
- Hold until it flashes three times, then release.
- Switch sound fonts
- Hold until it flashes four times, then release.
- Motion control on/off
- Hold until it flashes five times, then release.
- Power off
- Hold the button until the breathing light is off.
- Power saving mode
- No operation for 10 minutes.
Boot status · button
- Blaster
- Tap the button.
- Lock-up
- Hold until the breath light flashes once, then release.
- Switch blade color
- Hold until it flashes twice, release, then tap the button. To exit, hold until it flashes once, then release.
- FOC on/off
- Hold until it flashes three times, then release.
- Enter standby mode
- Hold until it flashes four times, then release.
Standby · gesture
- Enter boot status
- Twist the saber.
- Switch sound fonts
- Point blade upward, hold button and twist the hilt.
- Switch BGM
- Point blade downward, hold button and twist the hilt.
Boot status · gesture
- Switch blade color
- Point blade downward, hold button and twist the hilt.
- Force
- Point blade upward, hold button and twist the hilt.
- FOC
- Hit the saber.
- Drag
- Hold the button and hilt the blade.
- Melt
- Hold the button and thrust the blade forward.
- Enter standby mode
- Twist the saber.
